Turn the main switch A on (Fig 16-1).
When the glue has reached a temperature of 150ºC (302ºF),
LED C will come on (Fig. 16-1). This heating stage can last from
5 to 8 minutes, depending on the condition and quantity of
granulate. After this initial period, you can only glue short pieces.
To glue larger pieces, or to glue a series of items, you must
wait about 20 minutes for all the granulate to melt. (Open the
cover B (Fig. 12) to check this).
Ensure that all the adjustments in points 8 and 9
below have been performed before continuing.
Next, place the guide plate A (Fig. 27) over the piece to be
edged B (Fig. 27) and move the pressure roller C (Fig. 27) close
to the piece but without touching it.
Hold the machine over the piece with your right hand and turn
on the advance switch D (Fig. 27), which is on the handle for
your left hand. Wait for 2 or 3 seconds and move the edge with
your left hand through the guides E (Fig. 27) to the advance
roller F (Fig. 27). The edge will be automatically fed through
to pressure roller C (Fig. 27).
When the edge appears between the panel and the pressure
roller C (Fig. 27) allow around 2 cm of edge to pass with res-
pect to the panel and press roller C against the edge and the
panel (Fig. 26); the edge will stick and the turning movement
of the pressure roller will move the machine forward (Fig. 26)
continuously and consistently, at a speed of between 3.6 and
4 metres/minute until the end of the edge.
Do not try to go faster, maintain steady pressure on the pressure
roller and let the machine move at its own pace.
(Figure 16-1)
C
B
A
(Figure 12)
(Figure 27)
A
B
F
D
E
C
PEB200-PEB250 / Operating instructions - 31
