6
DOCKING STATION CONFIGURATION (Continued)
Step2
Connect your displays to the Docking Station, display connections vary by dock
Display 1 and 2 function via DisplayLink when connected with USB-A or USB-C. Display 3 is
supported via USB-C DP Alt Mode and will only output video when connected via USB-C.
For Illustrative Purposes
HDMI Cable
(Not Included)
Connect to HDMI Monitor
DisplayPort Cable
(Not Included)
Connect to DisplayPort Monitor
OR
HDMI DisplayPort
Display 3
(DP Alt Mode)
Display 1
(DisplayLink)
Display 2
(DisplayLink)
To Next Page
