VT3000-AI INSTALLATION GUIDE
t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com
1
Table of Contents:
2. Important Information
3. Overview
1.1 System Diagram
1.2 Packing List
1.3 Required Tools
1.4 VT3000-AI Details
8. System Installation Overview
2.1 MDVR Install
2.2 Power Supply, Ignition & IO Signal
2.3 Speed Signal & Serial Ports
2.4 Install SIM & SD Cards
10. Installation and Calibration
3.1 VT3000-AI Installation
3.2 VT3000-AI Camera Calibration
3.2 VT3000-AI Camera Calibration
3.4 DSM Camera FOV
3.5 DSM Calibration
3.5 Install the IPC Cab Camera (if applicable)
18. Speed Signal
19. Commissioning
To Next Page
