VT3000 INSTALLATION GUIDE
6
VT3000 Wiring:
t +44 (0) 1246 225 745 | e orders@visiontrack.com | w visiontrack.com
How to connect the VT3000 GPS Cable to the GPS Antenna Output.
Line up the cables to connect the VT3000 GPS Cable with the GPS Antenna Output
cable. Once the cables are lined up, push together to secure connection.
How to connect VT3000 IPC Cable to the VT-C26-IPC.
Line up the cables to connect the VT3000 IPC Cable with the VT-C26-IPC. Once the
cables are lined up, push together and twist the silver plate to secure connection.
VT3000 GPS Cable GPS Antenna Output
VT-C26-IPC Power/Video CableVT3000 IPC Cable
To Next Page
