VP-4 Pager – Programming User Guide – Version 1.01
3
Note: The section below applies to pagers with versions prior to 8108-V4.
Manual Programming Mode
The manual programming provides access to the settings of 6 capcodes, baud rate, frequency and data polarity.
1. Insert a battery and turn on the pager.
2. a. Press the ▲ key until the graphic menu is displayed.
b. Press the ► key until the display shows ON/OFF PAGER.
c. Press the ▲ key to turn off the pager.
3. Press and hold both the ◄ and ► keys until the password screen is displayed.
4. Enter the password using the ► key to select a digit and press ▲ key to navigate to the next password digit. After the 4th digit
was entered, press the READ/ON-OFF key.
Note: Default password is 1141.
Changing Capcodes
1. Enter the manual programming mode as described in the Manual Programming Mode section. The display will show
AD
SYSBFRQT.
2. a. Verify that the AD field is underlined or use the ► key to navigate the cursor to the AD field.
b. Press the ▲ key.
3. The display will show “1
: CCCCCCC 0”, where CCCCCCC is the capcode already programmed in to the pager.
The first digit label represents the number of the capcode (capcode ID) to be edited. For example, 1 represents capcode #1 and 6
represents capcode #6.
4. Select the ID of the capcode to be edited using the ▲ key.
5. Press the ► key. The cursor will move to the CAPCODE field.
6. a. Use the ▲ key to enter a respective capcode digit for each underlined digit in the capcode field.
b. Press the ► key to navigate to the next digit.
c. After the rightmost digit was entered, press the ► key. The cursor will move to the ON/OFF field.
Note: Standard capcode range is from 0000008 to 2097151. Invalid capcodes will be rejected.
7. Use the ▲ key to toggle between 0 (ON) and 1 (OFF) for the selected capcode. If you wish the capcode to be active, select 0
(ON).
8. Press the ► key. The cursor will move to the capcode ID field.
9. To program additional capcodes, press the ▲ key to select the capcode to be programmed and repeat steps 5-8 for each capcode.
Otherwise, press the READ/ON-OFF key to return to the main programming menu.
10. a. If additional programming is not required, press the ► key until the cursor is under the QT field.
b. Press the ▲ key exit the programming mode and return to standard operation mode.
