VP-4 Pager – Programming User Guide – Version 1.01
4
Changing Baud Rate, Polarity and Password
1. Enter the manual programming mode as described in the Manual Programming Mode section. The display will show
AD
SYSBFRQT.
2. a. Press the ► key to position the cursor under the SY field.
b. Press the ▲ key.
3. The display will show a sequence of data digits in two lines: “PRRRURRS TCL” on the first line and “B FFFF WWWW” on the
second line. Below is the description of each field:
P – Polarity 0 – Normal, 1 – Inverted
RRR Reserved (Do Not Modify)
U – Unread Messages Alarm 0 – Enable, 1 – Disable
RR Reserved (Do Not Modify)
S - Stand By Icon 0 - Disable, 1 – Enable
T - Sequential Lock Out Time 0 – Disable, 1 to 9 – One to Nine minutes
C - Add SPACE to Message 0 – Disable, 1 to 9 – One to Nine space characters
L - User Language 0 – Simple Chinese, 1– English, 2- Russian, 3 – Portuguese, 4 – Spanish
B – Baud Rate 0 – 512 bps, 1 – 1200 bps, 2 – 2400 bps
FFFF – Function Bits
WWWW – Password Numeric value from 0000 to 9999
4. a. Press the ► key to navigate the cursor to the desired field.
b. Press the ▲ key to enter a respective value for each underlined digit in the selected field.
5. Press the READ/ON-OFF key to return to the main programming menu.
6. a. If additional programming is not required, press the ► key until the cursor is under the QT field.
b. Press the ▲ key exit the programming mode and return to standard operation mode.
Changing Frequency
Note: Manual frequency modification may not be available for pagers shipped prior to June 2011 or for non-standard frequency
ranges. If the FR field in not displayed on the pager’s programming menu, the manual frequency programming feature is not
supported by the pager (VHF pagers may not support manual frequency modification although FR field is displayed).
In that case, the pager will have to be sent back to Visiplex for reprogramming or the frequency may be changed using an
optional programming hardware and software kit.
1. Enter the manual programming mode as described in the Manual Programming Mode section. The display will show
AD
SYSBFRQT.
2. a. Press the ► key to position the cursor under the FR field.
b. Press the ▲ key.
3. The display will show “FR:FFF-FFFFF MHz”, where FFF-FFFF is the frequency already programmed in to the pager.
4. a. Use the ▲ key to enter a respective frequency digit for each underlined digit in the frequency field.
b. Press the ► key to navigate to the next programmable digit.
c. After the rightmost digit was entered, press the ► key. The cursor will return to the first available frequency digit.
Note: The frequency must be within the frequency band supported by the pager (refer to the label at the back of the pager).
Invalid frequency or a frequency not within the band supported by the pager will render the pager inoperable.
5. Press the READ/ON-OFF key to return to the main programming menu.
6. a. If additional programming is not required, press the ► key until the cursor is under the QT field.
b. Press the ▲ key exit the programming mode and return to standard operation mode.
Note: Please contact Visiplex technical support (847-229-0250 or support@visiplex.com
) with any questions or if further assistance
is required.
