B
2 1/2" #8 FLAT HEAD (#2 ROBERTSON)264X
Step 1
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Attach together Truss Frame pieces (DC 4032 and DC 4034).
2) Repeat this build for a total of four 14’ Truss Frame assemblies.
4032 Split Truss Frame
Sub-Assembly
4034 Split Truss Frame
Member
24X
The components
should be t as tightly
together as possible
4032 Split Truss Frame Sub-Assembly
4034 Split Truss Frame Member
4X
