2 1/2" #8 FLAT HEAD (#2 ROBERTSON)264X
Step 2
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Attach together Truss Frame assemblies as shown in diagram.
2) Fasten all four corners in the same fashion.
The components
should be t as tightly
together as possible
14’ Truss Frame Assembly
Truss Frame Assembly must be square
Measure the Truss Frame to verify squareness.
Adjust the Truss Frame until both measure-
ments are equal.
A to D = B to C
A to D
B to C
8X
To Next Page
