VISSCHER CYPRESS - Page 18

F
2 1/2" #8 WASHER HEAD (#2 ROBERTSON)72X
Step 6
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Fasten the Panels (DC 3544) to the Post (DC 5125).

8X
5125 Post
Screws should
be in middle
3544 Shear Panel
3544 Shear Panel
5125 Post
Top view
Do not over sink
the screws
3544 Shear Panel
1880 Foam Gasket
