F
2 1/2" #8 WASHER HEAD (#2 ROBERTSON)72X
Step 7
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Repeat the Steps 5 and 6 for the other side.
2) Fasten the Shear Panel (DC 3544) to the Post (DC 5125).
8X
5125 Post
3544 Shear Panel 3544 Shear Panel
5125 Post
3544 Shear Panel
Top view
1880 Foam Gasket
5125 Post
3544 Shear Panel
knife
Do not over sink
the screws
To Next Page
