VISSCHER CYPRESS - Page 20

F
2 1/2" #8 WASHER HEAD (#2 ROBERTSON)72X
TRIGGER CLAMP (X2)
Step 8
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
12X
1880 Foam Gasket
1880 Foam Gasket
1) Use Foam Gasket (DC 1880) and adhere to Panel edges (DC 3505).
2) Fasten the Panels together. 

Screw from Shear
panel when possible.
Trigger clamp
Top view
Do not over sink
the screws
3505 Bifold Window
3505 Bifold Window
