F
2 1/2" #8 WASHER HEAD (#2 ROBERTSON)72X
Trigger clamp
Step 11
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Use Foam Gasket (DC 1880) and adhere to Panel edges (DC 3505).
2) Fasten the Panels Assemblies to the Structure.
Top view
Shear Panels Assembly
Shear Panels Assembly
8X
1880 Foam Gasket
Fastened from inside
Full Glass Windows Assembly
Full Glass Windows Assembly
To Next Page
