U
2 3/4" #10 RSS (T25 TORX)106X
Step 22
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
Do not fasten Rafters
to the Truss Frame at
this time.
6X
1) Attach the Common Rafters (DC 4130) to the Rafter Assembly.
2) Fasten the Common Rafters to the Rafter Assembly. Square the
Rafters to the Truss Frame. Do not fasten Rafters to the Truss Frame

90°
Square the Rafters
to the Truss Frame
4130 Common Rafter
