VISSCHER CYPRESS - Page 36

U
2 3/4" #10 RSS (T25 TORX)106X
Step 23
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Attach the Hip Rafters (DC 4129) to the Rafter Assembly.
2) Fasten the Hip Rafters in the locations shown in diagram.

4129 Hip Rafter
Do not fasten Rafters
to the Truss Frame at
this time.
12X
4129 Hip Rafter
4129 Hip Rafter 4129 Hip Rafter
4129 Hip Rafter
4129 Hip Rafter
