VISSCHER CYPRESS - Page 37

F
2 1/2" #8 WASHER HEAD (#2 ROBERTSON)72X
Step 24
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Fit the Collar Ties (DC 4147) to the other Collar Ties.
2) Fasten the Collar Ties to the Common Rafters as shown.
12X
1”
Collar Tie must be
aligned to the notch line
of the Common Rafter
4147 Collar Tie
4147 Collar Tie
