VISSCHER CYPRESS - Page 38

U
2 3/4" #10 RSS (T25 TORX)106X
Step 25
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Place and fasten the Left and Right Jack Rafters (DC 4131 and DC 4132) to
the Hip Rafters as shown.
Top view
16X
4131 Jack Rafter (Left)
4131 JR (Left)
4131 JR (Left)
4131 JR (Left)
4131 JR (Left)
4132 JR (Right)
4132 JR (Right)
4132 JR (Right)
4132 JR (Right)
4132 Jack Rafter (Right)
4131 JR (Left)
4132 JR (Right)
90°
90°
