VISSCHER CYPRESS - Page 42

B
2 1/2" #8 FLAT HEAD (#2 ROBERTSON)264X
Step 29
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Place and fasten the Upper Mid Strappings (DC 4136) to the Rafters.
 
4136 Upper Mid Strapping
24X
4136 Upper Mid Strapping
Do not stand on the Truss Frame or Rafter Assembly
Screws at Hip
Rafters must enter
on an angle.
Top view
