2 1/2" #8 FLAT HEAD (#2 ROBERTSON)264X
Step 30
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Place and fasten the Lower Mid Strappings (DC 4135) to the Rafters.
 
4135 Lower Mid Strapping
Do not stand on the Truss Frame or Rafter Assembly
4135 Lower Mid Strapping
24X
Screws at Hip
Rafters must enter
on an angle.
Top view
