B
2 1/2" #8 FLAT HEAD (#2 ROBERTSON)264X
Step 31
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Place and fasten the Left and Right Lower Roof Strappings (DC 4133 and DC 4134)
to the Rafters.
4133 Lower RS (Left)
4134 Lower RS (Right)
48X
4133 Lower RS (Left)
4133 Lower RS (Left)
4134 Lower RS (Right)
4134 Lower RS (Right)
Screws must enter
on an angle whenever
two strappings meet
4133 Lower Roof Strapping (Left)
4134 Lower Roof Strapping (Right)
Do not stand on the Truss Frame or Rafter Assembly
