VISSCHER CYPRESS - Page 5

1X
ROBERTSON BIT
1X
1/4" HEX HEAD BIT
A
1 1/2" #8 FLAT HEAD
(#2 ROBERTSON)
3X
B
2 1/2" #8 FLAT HEAD (#2 ROBERTSON)264X
F
2 1/2" #8 WASHER HEAD (#2 ROBERTSON)72X
I
1" #9 HEX HEAD234X
U
2 3/4" #10 RSS (T25 TORX)106X
G
1" #8 PAN HEAD
(#2 ROBERTSON)
86X
1X
TORX T 25 BIT
1X
TORX T 30 BIT
H
3/4" #14 HEX185X
V
4" X 5/16" RSS (T30 TORX)
10X
1X
3/8" HEX HEAD BIT
X
3 1/8" X 5/16" RSS (T30 TORX)44X
Y
1 1/2" X 1/4" RSS (T25 TORX)44X
A
1 1/2" #8 FLAT HEAD - BL
(#2 ROBERTSON)
3X
MEASUREMENTS ARE APPROXIMATE 0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
Hardware
56X
120X
76X
40X 16X
10X216X
6X
200X
8X
