MEASUREMENTS ARE APPROXIMATE 0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
Components
6X 3544 Shear Panel 6X 3505 Bifold Window
Panel
Panels
4X 5125 Post
2X 4086 Post (Pre-drilled)
1X 4087 Header (Pre-drilled)
1X 4088 Threshold
3X 1880 Foam Gasket
6X 7098 Screen
(with Bifold Window)
80”
80”
2X 3506 Full Glass
Window Panel
8X 4032 Split Truss Frame Sub-Assembly
4X 4034 Split Truss Frame Member
To Next Page
