I
1" #9 HEX HEAD234X
Step 44
0515 Cypress - Bélinda 14x14 Instructions V1.1 EN
1) Place the Peak Cap (DC 7209) at the very top of the Roof over top of the ends of the Hip ashing, as shown.
2) Make sure the Cap is pressed down tight and at to the Roong.
3) Secure the Peak Cap with screws on each side through the Cap and into the Roong.
Top view
4X
Screws must be fastened
through the top ribs of the
Roong sheet only.
7209 Peak Cap
7209 Peak Cap
To Next Page
