Appendix A
Trigger Types
The following tables list the different types of triggers that can be used in the
IoCore. The different types are accompanied with values and flanks.
A.1 Touch Screen
Trigger Type Trigger Value Flank Description
- - Change Button/Fader goes up or down
- - Down Button is pressed
- - Up Button is released
When editing the Touch Screen actionlist it will be possible to add different
kind of actions such as Button, Fader and Colour Picker. These elements will
be displayed in the VisualTouch software which is available free-of-charge from
the Visual Productions website.
A.2 Art-Net
Trigger Type Trigger Value Flank Description
Channel DMX address Change Channel changes
Channel DMX address Down Channel becomes non-zero
Channel DMX address Up Channel becomes zero
UniverseA - - A DMX level change in the universe
Receiving - Change Start receiving or loose Art-Net signal
Receiving - Down Lost Art-Net signal
Receiving - Up Start receiving Art-Net signal
41
