Rear Derailleur Guard Installation Instruction
2 3
5 6
Step 2: Using an 18mm wrench to turn
counterclockwise several times to loosen
the bolt, loosen the spacer and bolt.
Step 3:putting the rear derailleur guard on
the rear wheel axle.
Step 5: Putting the bolt on the axle. Step 6: Using an 18mm wrench to fasten bolt
several times clockwise.
1
4
Step 1: fining out the rear derailleur guard.
Step 4: Installing the spacer on the axle.
P11
