VITROKITCHEN CB9060IB - Page 7

Bottom heating
element
2000 W
Power
KW 4.00 4.00
Turbo heating
element
2 x 1250 W
Grill
Burner
Injecto
r
mm 1.20 0.85
Grill heating
element
2500 W
Power
KW 2.60 2.90
Supply voltage
220-400V, 50-
60 Hz
Hot plate 145 mm
(opt)
1000 W
Hot plate 180 mm
(opt)
1500 W
Reduced Flame Gas Cock Adjustment:
to adjust your oven acc. to the gas type, make the adjustment for reduced flame carefully by turning with a
small screwdriver as shown below on the screw in the middle of the gas cocks as well as nozzle changes (figure
5 and 6).
From LPG to
Natural gas
From Natural gas
to LPG
Rapid
Burner
3 turns
anticlockwise
3 turns clockwise
Semi-rapid
Burner
2.5 turns
anticlockwise
2.5 turns clockwise
Auxiliary
2 turns
2 turns clockwise
