Below is the distribution board (AE-239, -244, -23E, -23F) that draws power from a
30/60/95W PoE PSE. Note that the AE-239 and AE-244 provide 12V DC output.
Heater
Blower
IR angle selector
PoE power LED
24V DC OUT
PoE IN
Connectors to
the front IR
Wiper / Camera heater
PoE OUT
I/O terminal block
The PoE version housings have the same terminal pinouts with that of the 24V power
source models:
DO2 Tank water pump control, connects to IP camera's DO for manually triggering
washer.
DI2 Wiper control.
RS485+ RS485+, RS485- can be used to control IR illuminator beam angles, etc.
RS485- RS485-
DO+ +5V VCC
DI- GND
DO1 IR LED status
DI1 IR control, synchronizes day/night mode switching for IP camera. It is related to IR
cut lter.
