16
6. Rotate the camera clockwise until its alignment mark is aligned with the "C" mark.
7. Use the included T25 stardriver to tighten the 3 anti-tamper screws from the top. Make
sure all parts have been securely tightened.
6
7
HD WDR Pro
HD WDR Pro
The dimensions of the gooseneck installation are shown below.
380.4
258
579
C mark
