7
English
Conguration - Gooseneck
AM-221
AM-520
HEX SOCKET SCREW
NOTE:
When installing the mounting cap, take note that the orientation of the mounting cap can
affect the camera's shooting direction. You may need to remove the mounting cap, rotate,
and re-install it for the best orientation. Use the hex wrench to tighten its retention hex
socket screw when done.
