Technical Specications
Model
FD9365-HTV:
Vari-focal, Remote Focus
FD9365-EHTV:
Vari-focal, Remote Focus, -50 °C ~ 50 °C
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 512MB
Camera Features
Image Sensor 1/2" Progressive CMOS
Maximum Resolution 1920x1080
Lens Type Vari-focal, Remote Focus
Focal Length
f = 4 ~ 9 mm
f = 2.8 ~ 11.4 mm (equivalent focal length @
1/2. 8" )
Aperture F1.3 ~ 2.2
Auto-iris P-iris
Field of View
46° ~ 120° (Horizontal)
26° ~ 60° (Vertical)
53° ~ 152° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro II
Day/Night
Removable IR-cut lter for day & night
function
Minimum Illumination
0.04 Lux @ F1.3 (Color), 50IRE
0.002 Lux @ F1.3 (Color), 30IRE
0 Lux with IR LED on
Pan Range 353°
Tilt Range 65°
Rotation Range 180°
Pan/Tilt/Zoom
Functionalities
ePTZ: 48x digital zoom
(4x on IE plug-in, 12x built in)
IR Illuminators
Built-in IR illuminators, effective up to 50
meters with Smart IR II, IR LED*5
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.265, H.264, MJPEG
Maximum Frame Rate 60 fps @ 1920X1080
Maximum Streams 4 simultaneous streams
S/N Ratio 66 dB
Dynamic Range 140 dB
Video Streaming
Adjustable resolution, quality and constant
bit rate control, Smart Stream III
Image Settings
Time stamp, text overlay, ip & mirror;
Congurable brightness, contrast,
saturation, sharpness, white balance,
exposure control, gain, backlight
compensation, privacy masks; Scheduled
prole settings, video Rotation, 3DNR, DIS,
HLC
Audio
Audio Capability Two-way audio
Compression G.711, G.726
Interface
Built-in Mic
External Mic input
External line output
Effective Range 5 meters
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/
RTP/RTCP, IGMP, CIFS/SMB, SMTP, FTP, DHCP,
NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP,
802.1X, UDP, ICMP, ARP, SSL/TLS, NTCIP
Interface
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard
CAT5e & CAT6 cables which are compliant
with the 3P/ETL standard.
ONVIF
Supported, specication available at
www.onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
Alarm and Event
Alarm Triggers
Motion detection, manual trigger, digital
input, periodical trigger, system boot,
recording notication, camera tampering
detection, audio detection, MicroSD card
life expectancy
Alarm Events
Event notication using digital output, HTTP,
SMTP, FTP, NAS server and MicroSD card
File upload via HTTP, SMTP, FTP, NAS server
and MicroSD card
General
Connectors
RJ-45 cable connector for Network/PoE
connection
Audio line in
Audio line out
AC 24V
DC 12V
Digital input *2
Digital output *2
TV out
LED Indicator System power and status indicator
Power Input
FD9365-HTV:
AC 24V, DC 12V, IEEE 802.3af PoE Class 0
FD9365-EHTV:
AC 24V, DC 12V, IEEE 802.3at PoE Class 4
Power Consumption
FD9365-HTV: Max. 11.9 W
FD9365-EHTV: Max. 24.8 W
Dimensions Ø 155 x 138 mm
Weight 1,300 g
Casing IP66, IK10
