VIVOTEK
8 - User's Manual
IMPORTANT:
The FD9365-EHTV comes with an embedded heater and requires an 802.3at PoE
switch or 12V/24V 2A power.
1
2
3
4
6
5
8
7
10
LAN/PoE
100~240V
AC
ON
OFF
9
GE LAN GE LAN
802.3at
12/24V 1A or 2A
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
V Vandal proof.
NOTE:
Operating
Temperature
Consumption & Power Input
≥-10ºC,
FD9365-HTV,
FD8365-HTV-v2
PoE: 11.9W; AC 24V: 10.5W; DC 12V: 9W.
≥-40ºC,
FD9365-EHTV
PoE: 24.8W (PoE Plus mid-span or switch); AC 24V input: 21.8W;
DC 12V: 19.5W
