Vivotek FD9365-HTV Quick Installation Guide

1
14
# Name
1 AC 24V
2 AC 24V
3 DC 12V IN-
4 DC 12V IN+
5 VIDEO-OUT N
6 VIDEO-OUT P
7 DI- (Common GND for all DI, DO, MIC-IN, and AUDIO-OUT)
8 DI+ 1
9 DI+ 0
10 DO- 1 (If external devices are powered by external sources, can use DI- as
common ground)
11 DO- 0
12 DO+ (5V; if used, can be paired with DO- 0 and DO- 1.)
13 MIC-IN P
14 AUDIO-OUT P
- OR -
10
Ø 5 ~ 6.3mm
approx.
15cm
4 5 6
7
3/4"
Ø< 35mm
≤3/4”
8
64 GB
10
I
1
11
9
