Vivotek Fixed Dome Series - Page 3

3
English
Physical Description - Use
100m 100m 100m
PoE switch
AP-FXC-0200
PoE Extender
1 2
3
4
1 2 3 4
LA N
Po E
UPL INK
Po E
ON
OFF
4xFE PoE + 1xFE Switch
UPLINK
POWER
ON
* The NPT (National Pipe Taper) or PT pipes with male threads are user-supplied.
** The last conduit box does not need to contain a PoE extender.
Item No.
Screw
pack
M3x6 round head w/ washer (nickel and nylok) 7mm; (for securing
dome cameras to the base plate)
3
#6-32 L6 truss head (nickel and nylok) 8mm (for direct installation to a
junction box)
2
Anchors
3
Pan head M4x25, zinc-plated, self-tapping screws (for direct installation
to ceiling)
3
M3x6 pan washer head
2
