Vivotek IB9365-EHT-A - Page 16

VIVOTEK
16 - User's Manual
10. Attach the safety tether to the bottom of the camera.
icro
DI2-
DI2+
DO2-
DO2+
AC24V
AC24V
DC+
DC-
icro
DI1-
DI1+
DO1-
DO1+
MIC-
MIC+
AU-
AU+
11. Shown below are the pinouts of the DI/DO terminals.
