VIVOTEK
User's Manual - 177
© 2019 VIVOTEK INC. All Right Reserved
40
7.2.1 Status per Channel
Group: status_c<0~(n-1)> for n channel products
n denotes the value of "capability_nvideoin"
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
signal_detect
<boolean>
1/7
Indicates whether the video source is
connected or not.
* Only available when
capability_videoin_type is 0 or 1.
signal_type
ntsc,pal
1/7
The actual modulation type.
* Only available when
capability_videoin_type is 0 or 1.
7.3 Digital Input Behavior Define
Group: di_i<0~(n-1)> for n is the value of "capability_ndi" (capability_capability_ndi > 0)
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
normalstate
high,
low
1/1
Indicates open circuit or closed circuit
(inactive status)
7.4 Digital Output Behavior Define
Group: do_i<0~(n-1)> for n is the value of "capability_ndo" (capability_ndo > 0)
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
normalstate
open,
grounded
1/1
Indicate open circuit or closed circuit
(inactive status)
© 2019 VIVOTEK INC. All Right Reserved
41
7.5 Security
1. Group: security
NAME VALUE SECURITY
(get/set)
DESCRIPTION
privilege_do view, operator,
admin
1/6 Indicate which privileges and above
can control digital output
(capability_ndo > 0)
privilege_camctrl view, operator,
admin
1/6 Indicate which privileges and above
can control PTZ
(capability_ptzenabled > 0 or
capability_eptz > 0)
user_i0_name string[64] 6/7 User name of root
user_i<1~20>_name string[64] 6/7 User name
user_i0_pass password[64] 7/6 Root password
user_i<1~20>_pass password[64] 7/6 User password
user_i0_privilege view,
operator,
admin
6/7 Root privilege
user_i<1~20>_ privilege view,
operator,
admin
6/6 User privilege
