VIVOTEK
User's Manual - 249
© 2019 VIVOTEK INC. All Right Reserved
112
7.15 Play an Audio Clip
Group: audioclip_i<0~1> (capability_audio_audioclip=1)
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
name
string[40]
1/4
Specify the audio clip name that can
be played when an event occurs.
size
0,<positive integer>
1/4
The size of audio clip.
Group: audioclip (capability_audio_audioclip=1)
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
prerecord_seconds
1~10
1/4
Indicates the seconds that can be
waited before audio clip start to
record.
7.16 Motion Detection Settings
Group: motion_c<0~(n-1)> for n channel products
n denotes the value of "capability_nvideoin"
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
enable
<boolean>
4/4
Enable motion detection.
win_sensitivity
0 ~ 100
4/4
Sensitivity of all motion detection
windows.
* The value "0" is reserved for
compatibility and will not be used after
the version number (httpversion) is
equal or greater than 0400a.
Group: motion_c<0~(n-1)>_win_i<0~(k-1)>
n denotes the value of "capability_nvideoin", k denotes the value of "capability_nmotion".
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
enable
<boolean>
4/4
Enable motion detection window.
name
string[14]
4/4
Name of motion window.
polygonstd
0 ~ 9999,0 ~ 9999, 0
4/4
Coordinate of polygon window
© 2019 VIVOTEK INC. All Right Reserved
113
NAME VALUE SECURITY
(get/set)
DESCRIPTION
~ 9999,0 ~ 9999, 0 ~
9999,0 ~ 9999, 0 ~
9999,0 ~ 9999
position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_motion_wintype" =
polygon.
* Only available when std is listed in
"capability_motion_windomain"
objsize 1 ~ 100 4/4 Percent of motion detection window.
sensitivity
<Not recommended
to use this>
0 ~ 100 4/4 Sensitivity of motion detection window.
* We replace "sensitivity" with
"win_sensitivity".
* This parameter will not be used after
the version number (httpversion) is
equal or greater than 0400a.
polygonpx
<Not recommended
to use this>
0 ~ W,0 ~ H, 0 ~ W,0
~ H, 0 ~ W,0 ~ H, 0 ~
W,0 ~ H
W: 0~ The current
image width -1
H: 0~ The current
image height -1
4/4 Coordinate of polygon window
position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_motion_wintype" =
polygon.
* Only available when px is listed in
"capability_motion_windomain".
* It's recommended to use polygonsd
* This parameter will not be used after
the version number (httpversion) is
equal or greater than 0400a.
polygon
<Not recommended
to use this>
0 ~ 320,0 ~ 240, 0 ~
320,0 ~ 240, 0 ~
320,0 ~ 240, 0 ~
320,0 ~ 240
4/4 Coordinate of polygon window
position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_motion_wintype" =
polygon.
* Only available when qvga is listed in
"capability_motion_windomain".
* It's recommended to use polygonsd
* This parameter will not be used after
