160
PARAMETER
VALUE
SECURITY
(get/set)
DESCRIPTION
resolution
A list of <WxH>
<product
dependent>
0/7
Resolution options in current video mode.
These options are the possible options for
"videoin_c<n>_s<m>_resolution".
The last one is the maximum resolution in
current mode.
maxresolution
A list of <Integer>
0/7
Represent supported maximum resolution
of each stream in current video mode.
* The element number is defined as
"capability_nmediastream".
minresolution
A list of <Integer>
0/7
Represent supported minimum resolution
of each stream in current video mode.
* The element number is defined as
"capability_nmediastream".
* We support this parameter when the
version number (httpversion) is equal or
greater than 0304b.
maxframerate
A list of <Integer>
0/7
Indicate frame rate that the video source
outputs in current video mode.
One to one mapping to the resolution in
"resolution".
* The element number is defined as
"nresolution" in this group.
* This parameter may be changed when
"videoin_c<n>_cmosfreq"=50 or
"videoin_c<n>_modulation"=pal.
Ex: 30 fps is changed to 25 fps, 60 fps is
changed to 50 fps, and so on.
© 2019 VIVOTEK INC. All Right Reserved
161
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
mjpeg_maxframerate A list of <Positive
Integer> and "-"
0/7 Maximum fps that the device can encoded
with MJPEG on resolutions in current video
mode.
"-" means not support.
* One to one mapping to the resolution in
"resolution".
* The element number is defined as
"nresolution" in this group.
* This parameter may be changed when
"videoin_c<n>_cmosfreq"=50 or
"videoin_c<n>_modulation"=pal.
Ex: 30 fps is changed to 25 fps, 60 fps is
changed to 50 fps, and so on.
* Only available when 'mjpeg' is listed in
"capability_videoin_codec".
mjpeg_maxbitrate <positive
integer>, -
0/7 Maximum bitrates of MJPEG.
The unit is bps.
"-" means MJPEG does not support bit rate
control.
* Only available when 'mjpeg' is listed in
"capability_videoin_codec".
h264_maxframerate A list of <Positive
Integer> and "-"
0/7 Maximum fps that the device can encoded
with H.264 on resolutions in current video
mode.
"-" means not support.
* One to one mapping to the resolution in
"resolution".
* The element number is defined as
"nresolution" in this group.
* This parameter may be changed when
"videoin_c<n>_cmosfreq"=50 or
"videoin_c<n>_modulation"=pal.
Ex: 30 fps is changed to 25 fps, 60 fps is
changed to 50 fps, and so on.
* Only available when 'h264' is listed in
"capability_videoin_codec".
