VIVOTEK
User's Manual - 307
© 2019 VIVOTEK INC. All Right Reserved
170
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
Bit 1 => Supports Contrast or not.
Bit 2 => Supports Saturation or not.
Bit 3 => Supports Sharpness or not.
Bit 4 => Supports adjusting the image
to proper position horizontally or not.
Bit 5 => Supports adjusting the image
to proper position vertically or not.
hlm
<boolean>
0/7
Hightlight Mask: The function will
strengthen the image contrast and
mask the specified zone of image if
any strong spot-light exists.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0311a.
wdrpro_mode
0, 1, 2
0/7
0: Non-support WDR Pro
1: Support WDR Pro
2: Support WDR Pro and WDR Pro II
wdrpro_strength
0, 1
0/7
0: Non-support tuning strength of
WDR Pro
1: Support tuning strength of WDR Pro
* If
"capability_image_c<0~(n-1)>_wdrpro
"=1, this may be either 0 or 1.
wdrpro_supportlevel
0, <positive
integer>
0/7
This contains a list of positive integers,
split by comma.
If "wdrpro_mode" =1, then the value
indicate the support strength level of
WDR Pro.
If "wdrpro_mode" =2, then the first
number indicate the support strength
level of WDR Pro, and the scecond
number indicate the support strength
level of WDR Pro II.
wdrpro_affect
-,
exposurewin.mode
:fixed:auto,
0/7
When WDR Pro is enabled, some
features may become malfunction or
be forced to a given value. The
© 2019 VIVOTEK INC. All Right Reserved
171
NAME VALUE SECURITY
(get/set)
DESCRIPTION
exposurelevel:hidd
en:,
exposurelevel:fixed
:<x>,
exposurelevel:fixed
:<x>/<x>,
exposuremode:fixe
d:auto,
gammacurve:disabl
ed:,
exposurewin.mode
.blc:hidden:,
exposurewin.mode
.hlc:hidden:,
exposuretime:hidd
en:,
gaincontrol:hidden:
,
flickerless:unchang
ed:,
wdrc:enabled:,
wdrc:enabled:only
once,
wdrc:unchanged:,
<x>: nonnegative
integer
<product
dependent>
affected functions are list here.
The format is "Affect API
name":"Policy":"Description"
"Policy" can be categorized into
following groups:
- (disabled) : UI turns grey and users
can't select it.
- (unchanged) : UI keeps the status as
before and user can't change it.
- (hidden) : UI is hidden.
- (fixed) : UI is fixed to one selection or
value.
- (ranged) : UI is fixed to multiple
selections or values.
- (enabled) : UI is checked.
- (notsupport) : the affected function
is not available.
- (onlyonce) : when wdrpro is enabled,
wdrc is checked; when wdrpro is
disable, wdrc is unchecked.
"Affect API name" can be described in
hierarchy, such as
"exposurewin.mode.blc:disabled:"
which means blc exposure window is
disabled. API name can be one word
as well, such as
"exposurelevel:fixed:6" which means
exposurelevel is fixed to level 6.
"Description" can be a nonnegative
integer or string or NULL.
For example:
"exposurelevel:fixed:6/8/12" which
means exposurelevel is fixed to level
6, level 8 and level 12.
"-" means no feature is affected.
* When "wdrpro"=0, this value must
