VIVOTEK
User's Manual - 325
© 2019 VIVOTEK INC. All Right Reserved
188
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
different exposure values.
* Only available when
"capability_image_c<0~(n-1)>_
exposure_mode" is 1.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0310a.
exposure_bracketing_
range
A list of ratio
For example:
2x,3x,4x
0/7
The input parameter decides how
much ratio of exposure compensation
will be expanded on the next stream,
which is based on the original
exposure time (first stream).
* Only available when
"capability_image_c<0~(n-1)>_
exposure_bracketing_mode " is 1.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0310a.
privacymask_wintype
rectangle,
polygon,
3Drectangle
0/7
The supported mask window type.
"polygon": The window is a 2D
polygon shape.
"rectangle": The window is a 2D
rectangle shape.
"3Drectangle": The window is a 3D
rectangle shape.
privacymask_windom
ain
qvga, px, std, -
0/7
The domain to set an window.
"qvga": a 320x240 range to represent
the whole image.
"px": Locate a window in the image
with pixels.
"std": A normalized 0~9999 range.
"-": Not supported.
privacymask_ncolor
<Positive Integer>
0/7
Available total color numbers of
privacy mask.
agc_maxgain
"0,100",
"-"
0/7
Available range for
"videoin_c<n>_maxgain"
© 2019 VIVOTEK INC. All Right Reserved
189
NAME VALUE SECURITY
(get/set)
DESCRIPTION
“0,100” => 0~100 percent
"-" means "videoin_c<n>_maxgain" is
not available.
agc_mingain "0,100",
"-"
0/7 Available range for
"videoin_c<n>_mingain"
“0,100” => 0~100 percent
"-" means "videoin_c<n>_mingain" is
not available.
flickerless 0,1 0/7 0: Non-support flickerless
1: Support flickerless
flickerlessaffect -,
minexposure.lower
bound:fixed:x
or others
<x>: nonnegative
integer
<product
dependent>
0/7 When flickerless is enabled, some
features may become malfunction or
be forced to a given value. The
affected functions are list here.
The format is "Affect API
name":"Policy":"Description"
"Policy" can be categorized into
following groups:
- (disabled) : UI turns grey and users
can't select it.
- (unchanged) : UI keeps the status as
before and
user can't change it.
- (hidden) : UI is hidden.
- (fixed) : UI is fixed to one selection or
value.
- (ranged) : UI is fixed to multiple
selections or values.
- (enabled) : UI is checked.
- (notsupport) : the affected function
is not available.
"Affect API name" can be described in
hierarchy, such as
"exposurewin.mode.blc:disabled:"
which means blc exposure window is
disabled. API name can be one word
