VIVOTEK
User's Manual - 327
© 2019 VIVOTEK INC. All Right Reserved
190
NAME
VALUE
SECURITY
(get/set)
DESCRIPTION
as well, such as
"exposurelevel:fixed:6" which means
exposurelevel is fixed to level 6.
"Description" can be a nonnegative
integer or string or NULL.
"-" means no feature is affected.
* When "flickerless" = 0, this value
must be "-"
defog_mode
0,1
0/7
0: Non-support defog
1: Support defog
defog_strength
0, 1
0/7
0: Non-support tuning strength of
defog
1: Support tuning strength of defog
* If
"capability_image_c<0~(n-1)>_defog_
mode"=1, this may be either 0 or 1.
defog_supportlevel
0, <positive
integer>
0/7
The value indicate the support
strength level of defog.
defog_affect
-,
wdrc:unchanged:
contrast:hidden:
or others
<x>: nonnegative
integer
<product
dependent>
0/7
When defog is enabled, some features
may become malfunction or be forced
to a given value. The affected
functions are list here.
The format is "Affect API
name":"Policy":"Description"
"Policy" can be categorized into
following groups:
- (disabled) : UI turns grey and users
can't select it.
- (unchanged) : UI keeps the status as
before and
user can't change it.
- (hidden) : UI is hidden.
- (fixed) : UI is fixed to one selection or
value.
- (ranged) : UI is fixed to multiple
selections or values.
© 2019 VIVOTEK INC. All Right Reserved
191
NAME VALUE SECURITY
(get/set)
DESCRIPTION
- (enabled) : UI is checked.
- (notsupport) : the affected function
is not available.
"Affect API name" can be described in
hierarchy, such as
"exposurewin.mode.blc:disabled:"
which means blc exposure window is
disabled. API name can be one word
as well, such as
"exposurelevel:fixed:6" which means
exposurelevel is fixed to level 6.
"Description" can be a nonnegative
integer or string or NULL.
"-" means no feature is affected.
* When "defog" = 0, this value must
be "-"
aespeed 0,1 0/7 0: Non-support AE speed
1: Support AE speed
aespeedsupportlevel <positive integer> 0/7 The value indicate the support
strength level of aespeed.
* Only available when
"capability_image_c<0~(n-1)>_aespee
d" is 1.
aespeedsupportsensit
ivity
0,1 0/7 0: Non-support tuning the sensitivity
of AE converge speed.
1: Support tuning the sensitivity of AE
converge speed.
* Only available when
"capability_image_c<0~(n-1)>_aespee
d" is 1.
gammacurve 0,1 0/7 0: Non-support tuning Gamma curve
1: Support tuning Gamma curve
lowlightmode -,0,1 0/7 -: Internal parameter, must not open
to user.
0: Non-support low light mode
1: Support low light mode
