VIVOTEK
User's Manual - 7
SD card slotReset button
Inner View (IB9367)
Status LEDs
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
NOTE:
IMPORTANT:
The IB9365-EHT and IB9367-EHT come with an embedded heater and requires an
802.3at PoE switch or 12V/24V 2A power.
Operating
Temperature
Consumption & Power Input
≥-10ºC PoE - 24W (PoE Plus mid-span or switch)
≥-40ºC, heater on 12/24V input - 2A
≥-10ºC, heater off 12/24V input - 1A
1
2
3
4
6
5
8
7
10
LAN/PoE
100~240V
AC
ON
OFF
9
GE LAN GE LAN
802.3at
12/24V 1A or 2A
