VIVOTEK
256 - User's Manual
© 2020 VIVOTEK INC. All Right Reserved
117
NAME VALUE SECURITY
(get/set)
DESCRIPTION
record.
7.16 Motion Detection Settings
Group: motion_c<0~(n-1)> for n channel products
n denotes the value of "capability_nvideoin"
NAME VALUE
SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable motion detection.
win_sensitivity 0 ~ 100 4/4 Sensitivity of all motion detection
windows.
* The value "0" is reserved for
compatibility and will not be used after
the version number (httpversion) is
equal or greater than 0400a.
7.16.1. Motion Detection for Each Window
Group: motion_c<0~(n-1)>_win_i<0~(k-1)>
n denotes the value of "capability_nvideoin", k denotes the value of "capability_nmotion".
NAME VALUE
SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable motion detection window.
name string[14] 4/4 Name of motion window.
polygonstd 0 ~ 9999,0 ~ 9999, 0
~ 9999,0 ~ 9999, 0 ~
9999,0 ~ 9999, 0 ~
9999,0 ~ 9999
4/4 Coordinate of polygon window
position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_motion_wintype" =
polygon.
* Only available when std is listed in
"capability_motion_windomain"
objsize 1 ~ 100 4/4 Percent of motion detection window.
sensitivity
<Not recommended
to use this>
0 ~ 100 4/4 Sensitivity of motion detection window.
* We replace "sensitivity" with
"win_sensitivity".
* This parameter will not be used after
