VIVOTEK
User's Manual - 269
© 2020 VIVOTEK INC. All Right Reserved
129
7.25 Privacy Mask
Group: privacymask_c<0~(n-1)> for n channel products and m privacy mask window.
n denotes the value of "capability_nvideoin" and m denotes the value of
"capability_videoin_c<0~(n-1)>_nprivacymask"
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable privacy mask.
win_i<0~(m-1)>_enable
<boolean> 4/4 Enable privacy mask window.
win_i<0~(m-1)>_name string[14] 4/4 Name of the privacy mask window.
win_i<0~(m-1)>_left 0 ~ 320 4/4 Left coordinate of window position.
* Only available when
"capability_image_c<0~(n-1)>_privacy
mask_wintype" = rectangle.
win_i<0~(m-1)>_top 0 ~ 240 4/4 Top coordinate of window position.
* Only available when
"capability_image_c<0~(n-1)>_privacy
mask_wintype" = rectangle.
win_i<0~(m-1)>_width 0 ~ 320 4/4 Width of privacy mask window.
* Only available when
"capability_image_c<0~(n-1)>_privacy
mask_wintype" = rectangle.
win_i<0~(m-1)>_height 0 ~ 240 4/4 Height of privacy mask window.
* Only available when
"capability_image_c<0~(n-1)>_privacy
mask_wintype" = rectangle.
win_i<0~(m-1)>_polygo
n
0 ~ 320,0 ~ 240,
0 ~ 320,0 ~ 240
4/4 Coordinate of polygon window
position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_image_c<n>_privacymask
_wintype" = polygon.
* Only available when qvga is listed in
"capability_image_c<0~(n-1)>_privacy
mask_windomain".
win_i<0~(m-1)>_polygo
npx
0 ~ W,0 ~ H,
0 ~ W,0 ~ H,
4/4 Coordinate of polygon window
position.
© 2020 VIVOTEK INC. All Right Reserved
130
NAME VALUE SECURITY
(get/set)
DESCRIPTION
0 ~ W,0 ~ H,
0 ~ W,0 ~ H
W: 0~ The
current image
width -1
H: 0~ The current
image height -1
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_image_c<0~(n-1)>_privacy
mask_wintype" = polygon.
* Only available when px is listed in
"capability_image_c<0~(n-1)>_privacy
mask_windomain".
win_i<0~(m-1)>_polygo
nstd
0 ~ 9999,0 ~
9999, 0 ~ 9999,0
~ 9999, 0 ~
9999,0 ~ 9999, 0
~ 9999,0 ~ 9999
4/4 Coordinate of polygon window
position.
(4 points: x0,y0,x1,y1,x2,y2,x3,y3)
* Only available when
"capability_image_c<0~(n-1)>_privacy
mask_wintype" = polygon.
* Only available when std is listed in
"capability_image_c<0~(n-1)>_privacy
mask_windomain".
7.26 3D Privacy Mask
Group: privacymask3d_c<0~(n-1)> for n channel products and m privacy mask window.
(capability_image_c<0~(n-1)>_privacymask_wintype = 3Drectangle)
n denotes the value of "capability_nvideoin" and m denotes the value of
"capability_videoin_c<0~(n-1)>_nprivacymask"
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable the 3D privacy mask
color 0~"
capability_image_c<0~(n-
1)>_privacymask_ncolor"
-1
4/4 Privacy mask color
win_i<0~(m-1)>_name
string[40] 4/4 Name of the privacy mask
window.
win_i<0~(m-1)>_pan "capability_ptz_c<0~(n-1)
>_minpan" ~
"capability_ptz_c<0~(n-1)
>_maxpan"
4/4 Pan position of window
position.
* Only available when bit0 of
"capability_camctrl_c<0~(n-1)>_
