VIVOTEK
User's Manual - 333
© 2020 VIVOTEK INC. All Right Reserved
193
NAME VALUE SECURITY
(get/set)
DESCRIPTION
can't select it.
- (unchanged) : UI keeps the status as
before and
user can't change it.
- (hidden) : UI is hidden.
- (fixed) : UI is fixed to one selection or
value.
- (ranged) : UI is fixed to multiple
selections or values.
- (enabled) : UI is checked.
- (notsupport) : the affected function
is not available.
"Affect API name" can be described in
hierarchy, such as
"exposurewin.mode.blc:disabled:"
which means blc exposure window is
disabled. API name can be one word
as well, such as
"exposurelevel:fixed:6" which means
exposurelevel is fixed to level 6.
"Description" can be a nonnegative
integer or string or NULL.
"-" means no feature is affected.
* Only available when
"capability_image_c<0~(n-1)>_
exposure_mode" is 1 and hlc is listed
in "capability_image_c<0~(n-1)>_
exposure_winmode".
* We support this parameter when
the version number (httpversion) is
equal or greater than 0304a.
exposure_wintype inclusive,
exclusive,
-
0/7 The supported exposure window type.
"inclusive": The image inside a
window is the target area of exposure
control.
"exclusive": The image inside a
© 2020 VIVOTEK INC. All Right Reserved
194
NAME VALUE SECURITY
(get/set)
DESCRIPTION
window is omitted by exposure
control.
"-": Not supported.
* Only available when
"capability_image_c<0~(n-1)>_
exposure_mode" is 1.
exposure_windomain qvga, px, std, - 0/7 The domain to set an exposure
window.
"qvga": a 320x240 range to represent
the whole image.
"px": Locate a window in the image
with pixels.
"std": A normalized 0~9999 range.
"-": Not supported.
* Only available when
"capability_image_c<0~(n-1)>_
exposure_mode" is 1.
exposure_winnum 0, <Positive
Integer>
0/7 Indicate the number of custom
exposure windows.
* If no "custom" is listed in
"exposure_winmode", this should be
0.
* Only available when
"capability_image_c<0~(n-1)>_
exposure_mode" is 1.
exposure_ntsc_totalra
nge
A list of <Positive
Integer>
0/7 Available total range for NTSC analog
output.
* Only available when
"capability_image_c<0~(n-1)>_
exposure_mode" is 1.
* We support this parameter when
the version number (httpversion) is
equal or greater than 0301a.
exposure_pal_totalra
nge
A list of <Positive
Integer>
0/7 Available total range for PAL analog
output.
* Only available when
