VIVOTEK
10 - User's Manual
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
M Manual focus lens
NOTE:
IMPORTANT:
The E model camera comes with an embedded heater and requires an 802.3at PoE
switch.
1
2
3
4
6
5
8
7
10
LAN/PoE
100~240V
AC
ON
OFF
9
GE LAN GE LAN
802.3af or 802.3at
Operating Temperature Consumption & Power Input
-40ºC ~ 0ºC, heater on PoE 802.3at - max. 25W (PoE Plus mid-span or switch)
-40ºC ~ 0ºC, heater on DC 12V input - 20.4W, 1.7A
-40ºC ~ 0ºC, heater on AC 24V input 50~60Hz - 22W, 1.67A
≥0ºC, heater off PoE: 12.95W (37V~57V, 0.33A~0.22A); DC 12V input - 10.8W, 0.9A;
AC 24V -12.5W, 0.86A.
IB9365
