Specifications
All specications are subject to change without notice. Copyright 2010 VIVOTEK INC. All rights reserved.
c
Ver 1�2
．CPU: TI DM365 SoC
．Flash: 128MB
．RAM: 256MB
．Embedded OS: Linux 2.6
．Board lens, f = 3.6 mm, F1.8, Fixed
．IR corrected
．Removable IR-cut filter for day & night function
．56°(horizontal)
．41°(vertical)
．71°(diagonal)
．1/5 sec. to 1/25,000 sec.
．1/4”CMOS sensor in 1280 x 800 resolution
．0 Lux / F1.8 (IR LED on)
．Built-in IR illuminators, effective up to 15 meters
．IR LED*12
Networking
Alarm and
Event Management
On-board Storage
Security
Users
Dimension
Weight
Power
System
Lens
Angle of View
Shutter Time
Image Sensor
Minimum Illumination
IR Illuminators
Video
Image Settings
．10/100 Mbps Ethernet, RJ-45
．Onvif Support
．Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RTSP/RTP/RTCP, IGMP, SMTP, FTP,DHCP, NTP, DNS,
DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
．Triple-window video motion detection
．Tamper detection
．One D/I for external sensor
．Event notification using HTTP, SMTP or FTP
．Local recording of MP4 file
．Muilti-level user access with password protection
．IP address filtering
．HTTPS encrypted data transmission
．802.1X port-based authentication for network protection
．MicroSD/SDHC card slot
．Stores snapshots and video clips
．Live viewing for up to 10 clients
．
Ø
60 mm x 170 mm
．Net: 702 g
．12V DC
．24V AC
．Power consumption: Max. 4 W
．802.3af compliant Power-over-Ethernet (Class 2)
Housing
．Weather-proof IP66-rated housing
．Compression: H.264, MJPEG & MPEG-4
．Streaming:
Simultaneous multiple streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
．Supports activity adaptive streaming for dynamic
frame rate control
．Supports 3GPP mobile surveillance
．Frame rates:
H.264: Up to 30/25 fps at 1280x800
MPEG-4: Up to 30/25 fps at 1280x800
MJPEG: Up to 30/25 fps at 1280x800
．Adjustable image size, quality and bit rate
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness, contrast, saturation,
sharpness and white balance
．AGC, AWB, AES
．Automatic, manual or scheduled day/night mode
．Supports privacy masks
Operating
Environments
．Temperature: -20 ~ 50 °C (-4 ~ 122 °F)
．Humidity: 90% RH
Approvals ．CE, LVD, FCC, VCCI, C-Tick
Viewing System
Requirements
Installation, Management,
and Maintenance
Applications
．OS: Microsoft Windows 7/Vista/XP/2000
．Browser: Mozilla Firefox, Internet Explorer
6.x or above
．Cell phone: 3GPP player
．Real Player: 10.5 or above
．Quick Time: 6.5 or above
．SDK available for application development
and system integration
．Installation Wizard 2
．32-CH ST7501 recording software
．Supports firmware upgrade
Warranty
．12 months
Distributed by:
6F, No.192, Lien-Cheng Rd., Chung-Ho, Taipei County, Taiwan
Tel: +886 2 8245 5282
|
Fax: +886 2 8245 5532
|
E-mail: sales@vivotek.com
VIVOTEK USA, INC.
470 Lakeside Drive Suite C, Sunnyvale, CA 94085 USA
Tel: 408-773-8686
|
Fax: 408-773-8298
|
E-mail: salesusa@vivotek.com
System Overview
PC with
Recording Software
Router
Notebook with
Web Browser
3G Cell Phone
IP8332
External and Internal View
Reset Button
MicroSD/SDHC
Card Slot
IR LED
Lens
Light Sensor
