• If an outside antenna/satellite dish or cable system is to be connected to
the TV, make sure that the antenna or cable system is electrically grounded
to provide some protection against voltage surges and static charges.
• Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides
information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit,
size of the grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements of the grounding
electrode.
TELEVISION ANTENNA CONNECTION PROTECTION
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductors
(NEC Section 810-21)
Ground Clamps
Power Service Grounding Electrode System
(NEC ART 250, part H)
Electric Service Equipment
• Lightning Protection: For added protection of the TV during a lightning
storm or when it is left unattended or unused for long periods of time,
unplug the TV from the wall outlet and disconnect the antenna or cable
system.
• Power Lines: Do not locate the antenna near overhead light or power
circuits, or where it could fall into such power lines or circuits. Remember,
the screen of the coaxial cable is intended to be connected to earth in the
building installation.
