To turn color channels o and on:
1. From the COLOR CALIBRATION menu, use the Arrow buttons
to highlight Color Tuner, and then press OK. The Color Tuner
menu is displayed.
2. Use the Arrow buttons on the remote to highlight Red, Green,
or Blue.
3. Press the OK button to turn the color channel o or on. An X
appears over a color channel that has been turned o.
4. Use the Arrow buttons to highlight another color channel to
turn o or on. Only two color channels can be turned o at the
same time.
5. When you are nished with the color channels, press the EXIT
button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
To adjust the 11 Point White Balance settings:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the 11 Point White Balance menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Gain
and Color values you wish to adjust. Press the OK button and
use the Left/Right Arrow buttons to adjust the value. When
you are nished, press the OK button to save the setting.
3. When you are nished, press the EXIT button.
11 Point White Balance
Gain Red Green Blue
5% 0 0 0
Adjusting the Color Tuner Settings
The Color Tuner settings allow you to adjust the HSB color and 11
point white balance, turn color channels o for testing, and display
color bar, at, and ramp test patterns.
To adjust the HSB color settings:
1. From the COLOR CALIBRATION menu, use the Arrow buttons
to highlight Color Tuner, and then press OK. The Color Tuner
menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Hue,
Saturation, Brightness, Oset, or Gain of the color you wish
to adjust. Press the OK button.
3. Use the Left/Right Arrow buttons to adjust the value. When
you are nished press the OK button to save the setting.
4. When you are nished adjusting the color tuner settings, press
the EXIT button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
The Color Tuner, 11 Point White Balance, and test
patterns allow technicians to manually calibrate the TV.
Calibration requires specialized training, an input with
precisely set colors, and a specialized light meter.
18

Vizio D43n-E1 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	42.5 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Full-Array
Supported video modes	1080p
Contrast ratio (dynamic)	200000:1
Display number of colors	16.78 million colors
Motion interpolation technology	-
Number of OSD languages	3
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	ENG, ESP, FRE
Audio decoders	DTS, DTS TruSurround
RMS rated power	16 W
Number of speakers	2
3D	No
Composite video in	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Remote control type	XRT020
Sustainability certificates	ENERGY STAR
Power consumption (standby)	0.5 W
Power consumption (typical)	37.5 W
Product color	Black
Panel mounting interface	200 x 200 mm
Package depth	140 mm
Package width	1064 mm
Package height	693 mm
Package weight	12500 g

Weight and Dimensions

Depth (with stand)	210 mm
Width (with stand)	965 mm
Height (with stand)	623 mm
Weight (with stand)	9000 g
Depth (without stand)	64 mm
Height (without stand)	568 mm
Weight (without stand)	8800 g
