Vizio E50-C1 User Manual

1
12
Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult
WKH LQIRUPDWLRQEHORZ WR ȴQGWKH DSSURSULDWHPRXQW IRU\RXU 79
model:
Be sure the mount you choose is capable of supporting the weight
of the TV. After you have determined that you have the correct
mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
 3ODFHWKH79IDFHGRZQRQDFOHDQȵDWVWDEOHVXUIDFH%HVXUH
the surface is clear of debris that can scratch or damage the
TV.
3. Remove the base by loosening and removing the screws.
4. Attach your TV and wall mount to the wall, carefully following
the instructions that came with your mount.
Use only with a UL-listed wall mount bracket rated for the
weight/load of this TV.
WALL MOUNT SCREW LOCATIONS
E50-C1 E55-C1
Screw Size: M6 M6
Hole
Pattern:
ɋPP9[ɋPP+ ɋPP9[ɋPP+
Weight w/o
Stand:
27.56 lbs 34.17 lbs
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.

Vizio E50-C1 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Tuner	digital
Screen Size	49.5 inches, 50 inches
Refresh Rate	120hz
HDR	no
Number Of Speakers	2
USB Ports	1
RF Antenna	yes
Network	built-in wi-fi
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	vizio internet apps (v.i.a.)
Remote Control	smart
3D	no
Power Consumption	111 kilowatt hours
Depth with Stand	10.04 inches
Height with Stand	28.27 inches
Width with Stand	44.24 inches
Net Weight with Stand	28.44 pounds
Depth without Stand	2.52 inches
Height without Stand	25.91 inches
Net Weight without Stand	27.56 pounds
