Vizio E50-E3 - Wall Mount Specifications

English - 27
E50-E3 E60-E3 E70-E3
Screw Size: M6 M6 M6
Hole Pattern: 200 mm (V) x 200 mm (H) 400 mm (V) x 400 mm (H) 400 mm (V) x 400 mm (H)
Weight w/o Stand:
26.87 lb
(12.2 kg)
49.38 lb
(22.4 kg)
56.88 lb
(25.8 kg)
Wall-mount screw locations.
Note: The image shown here is for illustrative purposes only and may be subject to change. The actual number of ports and their locations may vary, depending on the model.
