Vizio E70-E3 Quick Start Guide

English - 25
To connect your Display to an external audio speaker:
1. Verify that your external audio speaker has an audio input that matches an available output on the
Display. (HDMI, 3.5mm, etc.) Note: HDMI connections must be connected to the HDMI-ARC port.
2. Turn both the Display and external audio speaker o.
3. Connect the appropriate cable (not included) to the Display and the external audio speaker.
4. Turn both the Display and external audio speaker on.
HDMI
CABLE
• CEC 2-WAY COMMUNICATION
• 2.0 - 5.1 DIGITAL AUDIO
• HDMI ARC ONLY AVAILABLE HDMI 1
• PCM, DTS, DOLBY DIGITAL
Sound bar system
Audio Receiver
DIGITAL
OPTICAL
CABLE
• 2.0 - 5.1 DIGITAL AUDIO
• PCM, DTS, DOLBY DIGITAL
COMPOSITE
CABLE
• ANALOG STEREO CONNECTION
• 2.0 CHANNEL
*External sound speakers and systems sold separately.

Vizio E70-E3 Specifications

General

Screen Type	led
Wall Mount	400mm x 400mm
Features	xled, xtreme black engine w/ 12 local dimming zones, vizio smartcast, compatible with google assistant and amazon alexa
Tuner	not included
Screen Size	69.5 inches, 70 inches
Refresh Rate	120hz
Closed Captioning	yes
HDR	yes
Built-In Speakers	yes
Surround Sound	dts studio sound, dts trusurround, dts truvolume, dolby digital plus
Speakers Output	20 watts
HDMI ARC Ports	yes
USB Ports	1
USB 2.0 Ports	0
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 4.1
Network	built-in wi-fi, ethernet
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	0
DVI	0
VGA Ports	0
Smart Applications	amazon alexa, google assistant
Remote Control	standard
3D	no
Depth with Stand	13 inches
Height with Stand	38.5 inches
Width with Stand	61.8 inches
Net Weight with Stand	58 pounds
Depth without Stand	2.9 inches
Height without Stand	35.7 inches
Net Weight without Stand	56.9 pounds
